Excellent silence and usability
be quiet! Silent Base 601 Window Black delivers the perfect combination of maximum silence and an excellent usability for remarkably quiet configurations.
- Noise dampening vents provide excellent air permeability with maximum silence
- Extra thick insulation mats of 10mm in the front, top and sides
- 2 preinstalled Pure Wings 2 140mm fans ensure a silent airflow
- 3-step fan controller caters for up to 3 fans
- PSU shroud and smart HDD slot covers provide a neat interior
- Fast and secure detachment of the side panels with push pins
- The power supply can be easily installed from the back of the case
- Detachable top bracket allows easy installation of radiators up to 360mm
- Generous dimensions make sure even E-ATX motherboards, large coolers and graphics cards fit well
- Side panel made of tinted and tempered glass
- 3 years manufacturer’s warranty
- Product conception, design and quality control in Germany
Specifications
Model
Silent Base 601 Window Black
Color option
Black
Motherboard compatibility
E-ATX (30.5 x 27.5cm) / ATX / M-ATX / Mini-ITX
Case size excl. stands (L x W x H), (mm)
553 x 245 x 484
Case size incl. stands (L x W x H), (mm)
553 x 245 x 502
PSU form factor
ATX PS/2
Weight (kg)
11.22
Expansion slots
7 + 2
Pre-installed fans
Fan @ top
-
Fan @ front
1x Pure Wings 2 140mm
Fan @ rear
1x Pure Wings 2 140mm
Dimensions (L x W x H), (mm)
Front: 140 x 140 x 25 / Rear: 140 x 140 x 25
Fan speed @ 100% PWM / 12V (rpm)
1000
Airflow @ 100% PWM / 12V (cfm / m3/h)
61.2 / 104
Air pressure @ 100% PWM / 12V (mm H2O)
0.76
Noise level @ 100% PWM / 12V (dB(A))
18.8
Voltage range (V DC)
5 - 12
Input power (W)
1.44
Input current (A)
0.12
Connector
3-pin
Lifespan (h / 25°C)
80,000
Fan controller
3-step fan controller (3x 3-pin)
Maximum fan installation
Top (mm)
3x 120 / 3x 140
Front (mm)
3x 120 / 3x 140
Rear (mm)
1x 140
Bottom (mm)
-
Side panel (mm)
-
PSU shroud
1x 120
Optional radiator installation
Top (mm)
120 / 240 / 360
Front (mm)
120 / 140 / 240 / 280 / 360
Rear (mm)
120 / 140
Bottom (mm)
-
PSU compatibility
Maximum dimensions excl. bottom fan (mm)
288
Maximum dimensions incl. bottom fan (mm)
288
Graphics card
HDD cage (in height of graphics card) installed (mm)
287
HDD cage (in height of graphics card) removed (mm)
449
Drive bay capacity
5.25 bays
-
3.5 slots (max.)
7
3.5 slots (scope of delivery)
3
2.5 slots (max.)
14
2.5 slots (scope of delivery)
6
Cooling
Max.construction height of CPU cooler unit (mm)
185
Airflow channel
Front / Top / Rear
Lighting
RGB LED illumination
-
LEDs synchronizable with RGB controller/motherboard
-
Expandable RGB controller
-
I/O Panel
USB 3.2 Gen. 2 Type C
-
USB 3.2 Gen. 1
2
USB 2.0
1
HD Audio I/O
Mic + Audio
Qi charger / Quick Charging Option
-
Insulation and damping
Top panel insulation mats
✓
Front panel insulation mats
✓
Side panel insulation mats
✓
Anti-vibration decoupled HDD
✓
Anti-vibration decoupled fan
✓
Anti-vibration decoupled PSU
✓
Anti-vibration decoupled motherboard-tray
✓
Removeable dust filters
Front
1
Bottom
1
Side panel
-
Material
Top cover
ABS / Steel
Front panel
ABS / Steel
Side panel
-
Side panel window
4mm tempered glass / Steel
Stands
ABS
Scope of delivery
Screw set (Drives/Motherboard)
✓
Rubber rail (pcs.)
-
Standoff (pcs.)
1 (for E-ATX)
LCS bracket (pcs).
-
HDD slot cover (pcs.)
5
Upper fan bracket (pcs.)
-
HDD panel rubber grommet (pcs.)
-
SSD bracket for PSU shroud
-
LED strips (pcs.)
-
Cable ties (pcs.)
6 (Velcro)
Service
Warranty (Years)
3
International hotline / free of charge
✓ / DE, FR
